General camera part number identification
| 1 | - | 2 | 3 | 4 | - | 5 | - | 6 | 7 |
Section 1
| CMOS-analog | |
| AHD | AHD signal-mini 4pin(male) |
| CVI | CVI signal-mini 4pin(male) |
| ED | Rigid camera type (endoscope) |
| HS | Hidden type |
| KDO | Wireless kit (included camera, transmitter, receiver) |
| KO | Wireless kit (included camera, transmitter, receiver) |
| MJ | Phone plug(D2.5mm) |
| MO | Mini 4pin(male) |
| MQ | Waterproof 4pin(male) |
| MX | Low light type-mini 4pin(male) |
| PVI | PVI signal-mini 4pin(male) |
| TVI | TVI signal-mini 4pin(male) |
| CMOS-digital | |
| EDD | Rigid camera type (endoscope) and USB 2.0 A type connector |
| FMD | USB 2.0 A type and snapshot & freeze function ( 2588 chip) |
| FMM | Micro USB OTG B type and snapshot & freeze function ( 2588 chip) |
| FMT | USB type C (UVC) and snapshot & freeze function ( 2588 chip) |
| FTD | USB 2.0 A type (UVC) snapshot & freeze function ( 1688 chip) |
| FTM | Micro USB OTG B type and snapshot & freeze function ( 1688 chip) |
| FTT | USB type C (UVC) snapshot & freeze function ( 1688 chip) |
| FXD | USB 2.0 A type (UVC) snapshot & freeze function ( with external 1688 chip) |
| FXM | Micro USB OTG B type and snapshot & freeze function ( with external 1688 chip) |
| FXT | USB type C (UVC) snapshot & freeze function ( with external 1688 chip) |
| HD | USB type A ( with external H.264 chip)/30fps |
| HM | Micro USB type B (with external H.264 chip)/30fps |
| HSD | Hidden type (USB A connector) |
| HSM | Hidden type (Micro USB OTG B type connector) |
| HST | Hidden type (USB A connector) |
| HT | USB type C (with external H.264 chip)/30fps |
| KD | USB 2.0 A type, sensor board to power board have cable length 30cm (ultra slim board) |
| KT | USB type C, sensor board to power board have cable length 30cm (ultra slim board) |
| KM | Micro USB OTG B type, sensor board to power board have cable length 30cm (ultra slim board) |
| MD | USB 2.0 A type (with external 1688 chip) |
| MM | Micro USB OTG B type ( 2588 chip) |
| MT | USB type C (2588 chip) |
| RD | Robot camera series USB 2.0 A type (1688 chip) |
| RM | Robot camera series Micro USB OTG B type (with external 1688 chip) |
| RT | Robot camera series USB type C (with external 1688 chip) |
| SD | USB 2.0 A type ( 2630 chip)/30fps |
| SFD | USB 3.0 connector (A type)/USB 2.0 interface /snapshot & freeze function (2588 chip) |
| SFTD | USB 3.0 connector (A type)/USB 2.0 interface(UVC) snapshot & freeze function ( 1688 chip) |
| SFXD | USB 3.0 connector (UVC) snapshot & freeze function ( with external 1688 chip) / 30fps |
| SM | Micro USB 2.0 OTG B type ( 2630 chip)/30fps |
| SMD | USB 3.0 connector (A type)/USB 2.0 interface ( 2588 chip) /30fps |
| SRD | Robot camera series USB 3.0 connector (A type)/USB 2.0 interface (1688 chip) |
| SSD | USB 3.0 A type (2630 chip)/60fps |
| ST | USB 2.0 type C (2630 chip)/30fps |
| STD | USB 3.0 connector (A type)/USB 2.0 interface ( 1688 chip) / 30fps |
| SVD | USB 3.0 A type (with external 5830 chip)/60fps |
| SVT | USB type C (with external 5830 chip)/60fps |
| SXD | USB 3.0 connector (A type)/USB 2.0 interface ( with external 1688 chip) / 30fps |
| FYD | USB 3.0 A type (with external 2630 chip)/60fps (model: B31105 series) ; USB 3.0 A type (with external M5288 chip on connector)/30fps (model: B36305 series) |
| TD | Hidden type(USB A connector) |
| THD | USB 3.0 A type (with M5288 chip-ISP on board)/30fps |
| THT | USB 3.0 USB type C (with M5288 chip-ISP on board)/30fps |
| TM | Micro USB OTG B type (1688 chip) |
| TT | USB type C (1688 chip) |
| YD | USB 3.0 A type (with external 2630 chip on connector)/60fps (model: B31105 series) ; USB 3.0 A type ( with external M5288 chip on connector)/30fps (model: B36305 series) |
| XD | USB 2.0 A type ( with external 1688 chip) |
| XM | Micro USB 2.0 OTG B type (with external 1688 chip) |
| XT | USB 2.0 type C (with external 1688 chip) |
| YD | USB 2.0 A type (with external 2630 chip)/30fps |
| YM | Micro USB 2.0 OTG B type (with external 2630 chip)/30fps |
| YT | USB 2.0 type C (with external 2630 chip)/30fps |
| Section 2 | |
| B | module type |
| BL | module type(left side view) |
| F | Square type (iron enclosure) with bracket |
| Section 1 is "MO", camera connector will be RCA(male)/DC JACK (* available for Tube type) | |
| FPC | Flexible printed circuit camera |
| L | Snake type (with flexible iron pipe protect cable) |
| M | with motion detect function |
| N | Square type (hidden) |
| NL | Square type (plastic enclosure) side view or up view |
| NS | Small square type (hidden) with bracket |
| P | Square type (plastic enclosure) with bracket |
| R | Bullet type with bracket |
| S | Forming type (built in epoxy resin) |
| SL | Forming type side view(built in epoxy resin) |
| T | Tube type |
| TCAM | Dual camera |
| V | Tube type with LED and dimmer |
| W | Waterproof type |
| Z | Slim forming type |
| ZL | Slim forming type side view |
| Section 3 - Camera series and camera size |
| Section 4 | |
| A | with microphone |
| AD | with microphone (MS-3300) *available for analogy series |
| AG | with microphone (MS-8300) *available for analogy series |
| C | Camera with cable length |
| Concealed lid (available for R5910C-3G, R5610C-3G ) | |
| D | Down view |
| E | with OSD function(analog), GPIO pin(digital) |
| J | Camera frame rate is fixed at 60 fps (available for MD-T1003 series) |
| K | Camera frame rate is fixed at 15 fps |
| KL | Camera frame rate is fixed at 15 fps and with LED |
| L | Camera with LED |
| LC | Camera with cable length and LED |
| LH | Camera with cable length and MS LED(high brightness LED) |
| LSC | Camera with cable length and LED and with thread on tube back (available for MO-T3506 / MO-T35506 series) |
| LW | 4 wires output (with LED) |
| Q | Spring cable (available for MD-N41xx series) |
| R | Round type (available for MD-B31114, TD-B31109, TD-B20908) |
| S | Straight cable (available for MD-N41xx series) |
| SW | with thread on tube back (available for MO-T3506 series) |
| U | Up view |
| Q | Spring cable (available for MD-N41xx series) |
|
Section 5 - Lens code which is used in the camera Section 6 - Camera system (NTSC/PAL or EIA/CCIR) available for analog series Section 7 - Custom camera by serial number |
General lens part number identification
| 1 | 2 | 3 | 4 | - | 5 | - | 6 |
Section 1 -Types of lens or pixel (pin hole / board / megapixel)
| L | G type lens, Board Lens |
| LP | Pin hole lens |
| 1M | 1 Megapixel Lens |
| 2M | 2 Megapixel Lens |
| 3M | 3 Megapixel Lens |
| 5M | 5 Megapixel Lens |
| 8M | 8 Megapixel Lens |
| 12M | 12 Megapixel Lens |
Section 3 -Aperature (F)
Section 4 -Lens coating (AR/IR)
Section 5 -Lens mount/size (Mxx)
Section 6 -Custom lens by serial number
NOTE: some might not fit the general code meaning
General Led part number identification
| 1 | - | 2 | 3 | 4 | 5 |
Section 1 -Types of LED
| LS | LED series |
Section 3 -LED board inner-diameter
Section 4 -LED quantity
Section 5
| H | High intensity LED |
NOTE: some might not fit the general code meaning
General cable accessary part number identification
| 1 | - | 2 | 3 | 4 | 5 | - | 6 |
Section 1 -Cable types(AF-XXXXX)
Section 2 -Total cable length (three digits)
Section 3 -Front side connector
Section 4 -End side connector
Section 5 -Second end side connector (if needed)
Section 6 -Serial number
NOTE: some might not fit the general code meaning
