CVBS CAMERA
Board Camera
MX-B5609-2V
1/3" Color CMOS 488p High Sensitivity
Ø 8.8 x 16.2 mm
Description

The MX-B5609-2V is a Ø 8.8 x 16.2 mm 1/3" color CMOS star light board camera module, delivering 728 x 488 resolution at 30 fps with exceptional low-light performance down to 0 lux for security surveillance applications.

It features a 92° view angle lens with a variety of optional view angles available, an optional external microphone, adjustable frame rate options, and a CVBS analog output for straightforward integration.

This camera module is manufactured in Taiwan by MISUMI, delivering a 63.7 dB dynamic range and 46.4 dB signal-to-noise ratio for clear, reliable analog video output.

☆ This photo was taken with the lights turned off in the office at 0 Lux environment.
MISUMI Camera Normal B/W camera
Feature
• 488p Resolution
  (728 x 488 @ 30 fps)
• 1/3" Color CMOS
• View Angle 92°
  49˚ / 60˚ / 67˚ / 72˚ / 83˚ / 78˚ / 92˚ / 153˚ (Optional)
• White / IR 850 nm / IR 940 nm LED (Optional)
• 3 Wires Output
• 15~30 fps / 15 fps (Optional)
• External Microphone (Optional)
• Mini Camera, Compact Size and High Image Quality Camera Module
Choose Model
✦ MX-B5609-2V
✦ MX-B5609-2V ✦ MX-B5609L-2V (With LED) ✦ MX-VB5609L-2V (With LED / Dimmer) ※ MX-B5609-2V (Need Customized Request)
*For customizations, kindly email our sales team and specify your requests.
Video Format NTSC / PAL
Image Sensor 1/3" Color CMOS
Resolution 728 x 488 @ 30 fps
Pixel Size (μm) 6.35 x 7.4
Image Area (mm) 4.6228 x 3.6112
Scan Mode Progressive
Sensitivity 13.8 V / (Lux-sec)
Dynamic Range 63.7 dB
S/N Ratio 46.4 dB
Shutter Rolling
Lens
2.8 mm / F 3.9
View Angle 92˚
Focus Distance (mm) Infinity
LED N/A (Optional)
Power Supply DC 3.3V
Power Current 80 mA
Interface CVBS
Dimension (mm) Ø 8.8 x 16.2
• 0-lux security surveillance in fully dark environments
• Covert monitoring requiring audio capture via external microphone
• Legacy CCTV or DVR system upgrades requiring CVBS compatibility
• Night-vision-critical industrial or perimeter monitoring
• Low Light Inspection
• Night Time Inspection
• Wild Animal Observation
• Security Surveillance Inspection
• Non-Destructive Testing
• Industrial Inspection
• Drain Pipe Inspection
• Pipeline Inspection
• Automotive Inspection
• Engine Valves Inspection
• Robotic Inspection
• Tube Inspection
• Air Duct and Vent Inspection
• Machine Inspection
• Machine Vision
• Aerospace
• Aviation Inspection
• Security Monitoring
• Life Sciences
