Product
USB CAMERA
Board Camera
FKD-VB31105LH-49
1/6" Color CMOS 1080p Short Head
Ø 7.5 x 10 mm
Description

The FKD-VB31105LH-49 is a Ø 7.5 x 10 mm mini board camera module built around a 1/6" color CMOS sensor, delivering 1920 x 1080 resolution at 15 to 30 fps with excellent low-light sensitivity.

It features snapshot and freeze frame capability along with dimmer LED control, letting users capture and hold a still image and adjust illumination brightness as needed. The module includes 10 built-in high-intensity white LEDs for strong, adjustable illumination.

Its 3.4 mm F6.0 lens provides a 49° field of view, with an extensive range of alternative angles from 22° to 158° also available, and connects via USB 2.0 Type-A. This camera module is manufactured in Taiwan by MISUMI, ensuring consistent quality and reliable supply.

Feature
• 2 Megapixels
  (1920 x 1080 @ 15~30 fps)
• 1/6" Color CMOS
• View Angle 49°
   22° / 29° / 34° / 39° / 49° / 65° / 67° / 88° / 93° / 120° / 158° (Optional)
• High-Intensity White LED x 10
   White LED / IR 850nm / IR 940 nm (Optional)
• Interface USB 2.0
   Interface USB 3.0 (Optional)
• USB 2.0 Type A Connector
• Mini Camera, Compact Size and High Image Quality Camera Module
Choose Model
✦ KD-B31105-49
✦ KD-B31105-49 ✦ KD-B31105LH-49 (With LED) ✦ KD-VB31105LH-49 (With LED / Dimmer) ✦ FKD-VB31105LH-49 (With LED / Dimmer + Snapshot and Freeze) ※ FKD-VB31105LH-49 (Need Customized Request)
*For customizations, kindly email our sales team and specify your requests.
Video Format MJPEG / YUV
Image Sensor 1/6" Color CMOS
Resolution 1920 x 1080 @ 15~30 fps
Pixel Size (μm) 1.4 x 1.4
Image Area (mm) 2.73 x 1.55
Scan Mode Progressive
Sensitivity 0.553 mV / (Lux-sec)
Dynamic Range 73.3 dB @ 15.5x gain
S/N Ratio 38.3 dB
Shutter Rolling
Lens
3.4 mm / F 6.0
View Angle 49°
Focus Distance (mm) FID 45-20-80
LED White High-Intensity LED x 10
Power Supply DC 5 V
Power Current 190 mA
Interface USB 2.0 Type A
Dimension (mm) Ø 7.5 x 10
• Industrial Borescopes and Pipe/Duct Inspection Requiring Snapshot Capture
• Medical and Veterinary Endoscopy Devices
• Confined-Space Equipment Inspection
• Quality Control and Documentation Imaging
• Robotics and Automation Vision Systems
• Portable Handheld Inspection Cameras
• Non-Destructive Testing
• Industrial Inspection
• Drain Pipe Inspection
• Pipeline Inspection
• Automotive Inspection
• Engine Valves Inspection
• Robotic Inspection
• Tube Inspection
• Air Duct and Vent Inspection
• Machine Inspection
• Machine Vision
• Aerospace Inspection
• Aviation Inspection
• Security Monitoring
• Life Sciences
• Search and Rescue
